Vancol Electric Products Catalogs

13 / 84

06
LC Type Terminal Block
Item
No .
Section
size( 2 mm )
L
(mm)
B
(mm)
H1
(mm)
H2
(mm)
E1
(mm)
Ø1
(mm)
LC-4
LC-7S
LC-7B
53.05
83.8
110
22.7
25.4
35
21.3
24.7
29
14
16.65
21
9
19.7
28
5.4
5.8
8
Material:
Plastic: polycarbonate
Insert: brass
E2
(mm)
9
13
Ø2
(mm)
7
10.5
H1
H2
B L
L
Ø
E
Ø1 Ø2
E2 E1
LC-4
LC-7S
L
Ø1 Ø2
E2 E1
LC-7B
B4 Type Terminal Block (4 Pole)
Plastic: PA, PE
Insert: brass
Item
No .
Section
size ( 2 mm )
L
(mm)
B
(mm)
H1
(mm)
H2
(mm)
E
(mm)
Ø
(mm)
B4 16 77.5 27.3 13.3 22.9 5.6 14.6
H2
H1
L
Ø
B
E
4×16
1×25 + 6×16
1×50 + 6×35
