12 / 84
05
TERMINAL BLOCKS
Technical Data:
Maximum operating temperature: +85
℃
Heat resistance: +130
℃
Building according to standards: EN60998-1, EN60998-2-1
C Type Terminal Block (10 Pole)
B
H1
H2
E
L
Ø
Item
No .
Section
size
(
2
mm )
L
(mm)
B
(mm)
H1
(mm)
H2
(mm)
E1
(mm)
Ø
(mm)
C22
C23
C24
C25
C26
2.5
4
6
10
16
120
121
145
169
212
18
20
22
25
32
19
18
23
26
33
11
10
12
17
20
12
12
14.5
17.5
21
4.16
4.76
5.83
7.58
10.18
T Type Terminal Block (Single Pole)
Item
No .
Section
size
(
2
mm )
L
(mm)
W
(mm)
H1
(mm)
H2
(mm)
E
(mm)
Ø
(mm)
Material:
Plastic: polycarbonate
Insert: brass
T-1
T-2
6
6
19.9
21.8
13.65
14
19.8
24
14.1
15.5
7.3
5.6
6.5
H1
H2
L
W
H1
H2
L
W
E
Ø
Ø
T-1
T-2
C series one pole movable terminal posts with 1, 2, 5, 10 pole are suitable for posts with
1, 2, 5,10 pole are suitable for continuity or branching-off connections, between
electric conductors.
Materials:
Insert: Brass
Screws: Zinc Plated Steel
Insulating body: Polycarbonate
