H Type Terminal Block (12 Pole)
H series 12 pole terminal blocks are suitable for continuity or branching-off connectors
between electric conductors.
Material
:
Insert: brass
Plastic: PE, PP or PA
Color: Natural, Black, White
Technical Data
:
Max. Operating temperature: -5
℃
~+85
℃
for PE
According to :EN60998-1 EN60998-2-1
1.2-2.5mm
H-3
H-6
H-10
H-15
H-20
H-30
H-60
H-80
H-100
H-150
Item No .
Section size
2
(mm )
2.5/4
6
10
12
14
16
25
30
35
40
L
(mm)
92
113
131
135
141.6
168
190
201
228
261
W
(mm)
15.5
17.3
20.85
22.65
22.65
25.5
30.8
36
38
44
H
(mm)
12.7
13.9
16.4
18.25
18.4
20.0
25.2
22.65
33
33
A
(mm)
5.5
6.5
7.25
8.25
8.5
8.0
11.5
12.1
13.8
21.2
B
(mm)
8.0
10.0
11.2
11.5
12.2
15.5
16.5
18.15
19.4
22
L
H
W
H
W
Ød
Rated
current
(A)
3
6
10
15
20
30
60
80
100
150
Ød
(mm)
3.0
3.3
3.8
4.2
4.5
5.5
6.3
6.9
7.4
8.3
A
B
