Material:
Insert: brass or brass nickel plated
Plastic: PA 94V-2 grade, working temperature: -35 to 125
℃
, short time 140
℃
.
Voltage : 230~450V
Color: Natural, Grey, Blue
℃
LT Type Terminal Block
W
L
H
Ød1
Ød2
Item
No .
Section
size
(
2
mm )
L
(mm)
W
(mm)
H
(mm)
Ød1
(mm)
LT-16
LT-25
LT-35
LT-50
LT-70
LT-95
LT-120
16
25
35
50
70
95
120
41
47.6
55.2
65
66.8
71
73.5
17
20.8
24.4
27
29
33.5
35.8
32
37.8
42.5
48.5
52.5
56.8
61
4.3
4.3
4.3
5
5
5
5
Ød2
(mm)
14.5
×
4.8
17
×
6.8
19
×
8.4
22
×
9.3
25
×
10.5
29
×
12.6
33
×
13.8
Screw
size
M8
M10
M12
M14
M16
M18
M20
8T Type Terminal Block (8 Pole)
Insulating Material
: PA
Insert
: Brass
Item
No .
Section
size
(
2
mm )
L
(mm)
W
(mm)
H1
(mm)
H2
(mm)
E
(mm)
8T16
8T25
8T35
8T50
8T70
16
25
35
50
70
173
206
251
260
271
26.4
31.4
41.5
42
43.5
23.6
27
32.3
34
37.9
12.1
13.1
17.3
17.3
21.5
21
24.8
30.3
32
33.2
Ø
(mm)
8
×
5
9
×
6
12
×
8
14
×
8.5
16
×
9
Order ref.
(PCS/CTN)
200
100
80
60
40
H
1
H
2
L
E
Ø
Color
: Grey , White
Voltage
: 230~450V
