Technical parameter
Type
2
(mm )
Main line
section
2
(mm )
Branch
section
(A)
Rated
current
(V)
Rated
voltage
Dimensions
Screw
diameter
Torque
JT Type Terminal connectors
JT series terminals connctors is used for branch line " T " connection in the construction
and industrial electric equipment when cable trunk can't be cut off, on the basis of
advantage of JT1 series T-type connector, it show its highlight of safety protection, and
makes a breakthrough in design, This launch if the connector, not only greatly increases
the performance/price ratio, but also expands the service range, so at to provide
designer with enough imagination space, it stands out in the industry of cable T-type
connector.
The products are in conformity with IEC 60947-7-1, GB1404B.7.1 and JB/9659.1
General
JT-50(35)
JT-70(50)
JT-95(70)
JT-120(95)
JT-150(120)
JT-185(150)
JT-240(185)
150
192
232
250
353
353
400
1000
1000
1000
1000
1000
1000
1000
16-50
25-70
25-95
25-120
35-150
35-185
35-240
6-35
10-50
10-70
16-95
25-120
25-150
25-185
Striping
length
(mm)
(N.m)
M8
M10
M10
M10
2xM10
2xM10
2xM10
12
20
20
20
20
20
20
25/25
30/30
30/30
30/30
30/30
30/30
30/30
Type
(mm)
A
JT-50(35)
JT-70(50)
JT-95(70)
JT-120(95)
JT-150(120)
JT-185(150)
JT-240(185)
39
47
47
70
70
70
70
(mm)
B
(mm)
C
(mm)
D
(mm)
H
35
44
44
57
57
57
57
29
35
35
57
57
57
57
27
35
35
47
47
47
47
58
73
81
90
90
100
100
H
A
C
D
B
