Screw On Wire Connector
Material:
UL nylon66, with spring inside.
Usage:
peel wire coat, insert the wire in, then tighten.
Item No .
P71
P72
P73
P74
P75
P78
D
(mm)
Suitable Wire
Height
(mm)
Width
(mm)
15
18
23
24
28
32
9
10
11
14
16
18
7
8
10
11
13
14
2
0.5-1.0mm (AWG22-18)
2
1.0-1.5mm (AWG18-16)
2
1.5-2.5mm (AWG16-14)
2
2.5-4mm (AWG14-12)
2
4-6mm (AWG12-10)
2
10-16mm (AWG 6)
D
W
H
Screw On Wire Connector
Material:
UL nylon66, with spring inside.
Usage:
peel wire coat, insert the wire in, then tighten.
P1
P2
25
29
18.0
22.0
9
11
2
4-6mm (AWG12-10)
2
6-12mm (AWG8-6)
Item No .
D
(mm)
Suitable
Wire
Height
(mm)
Width
(mm)
D
W
H
Color
Yellow
Red
Double Wings Screw On Wire Connectors
Material:
UL nylon66, with spring inside.
Usage:
peel wire coat, insert the wire in, then tighten.
P11
P12
P13
P15
P17
25.4
27.7
30.5
32.6
39.5
18
17.8
23.1
25.5
31.7
9.5
10
12
14.6
17.8
Item No .
D
(mm)
Height
(mm)
Width
(mm)
Color
Yellow
Taupe
Red
Grey
Blue
2
0.5-2.5mm (AWG22-14)
Suitable
Wire
2
0.5-4mm (AWG22-12)
2
1.0-6mm (AWG18-10)
2
2.5-16mm (AWG14-6)
2
1.0-10mm (AWG18-8)
D
W
H
