HEAT-SHRINKABLE TUBE
29
HTS-D series double-wall thermal shrinkable bushing
Ø2.4
Ø3.2
Ø4.8
Ø6.4
Ø7.9
Ø9.5
Ø12.7
Ø15.0
Ø19.1
Ø25.4
Ø30.0
Ø39.0
Ø50.0
Ø64
Ø75
Ø90
Ø100
Ø125
HTS-D series is a semi-conducting thermal shrinkable bushing coated with a layer of
thermosol inside. Its external layer consists of radiation cross-linked polythene, and its
internal layer is the specially designed adhesive internal wall. When it is heated, the
internal thermosol will shrink to the external wall and fill the clearance. When it is cooled,
the thickness of double walls is very even and solid. It is widely used for the water-
tightness and air-tightness of wiring for electronic equipments, the sealing of wiring
branch, rust protection of metal wires, and the remedy of wires and cables. It can prevent
the polymer chains from loosening and falling, such as pool lamp, auto pipeline, and
advanced lines.
Application: -55
℃ ～
125
℃;
Initial shrinking temperature: 70
℃;
Full shrinking temperature: 125
℃;
Melting temperature of internal adhesive layer: 70
℃ ～
80
℃
Shrinking ratio: 3:1
Seal, water-proof, strong flexibility, convenient use, able to shrink when heated with oven
or hot air gun; timely supply and delivery; and large production.
Color standard: Black (Other colors are upon the clients' needs).
Size Dimension before
shrinking
(mm)
Internal
diameter
Dimension after
shrinking
(mm)
Wall
thickness
Standard
packaging
(m/disc)
Item No .
0.80
1.00
1.60
2.20
2.70
3.20
4.20
5.20
6.30
8.50
10.2
13.5
17.0
21.0
25.0
30.0
34.0
42.0
2.7±0.3
3.5±0.3
5.1±0.3
6.8±0.4
8.3±0.4
9.9±0.4
13.2±0.5
15.5±0.5
19.6±0.5
26.2±0.8
30.5±0.8
39.8±0.8
50.0±0.8
≥
64
≥
76
≥
90
≥
100
≥
125
0.7±0.15
0.90±0.15
1.0±0.15
1.2±0.15
1.3±0.15
1.4±0.15
1.6±0.20
1.8±0.20
2.0±0.20
2.1±0.20
2.2±0.20
2.4±0.20
2.7±0.25
3.0±0.25
3.0±0.30
3.0±0.30
3.0±0.30
3.0±0.30
0.30±0.10
0.35±0.10
0.40±0.10
0.45±0.12
0.50±0.12
0.50±0.12
0.50±0.12
0.55±0.12
0.55±0.12
0.55±0.15
0.60±0.15
0.60±0.15
0.70±0.15
0.70±0.15
1.00±0.20
1.00±0.20
1.00±0.20
1.00±0.20
Internal
diameter
Wall
thickness
200
200
100
100
100
1.22
1.22
1.22
1.22
1.22
1.22
1.22
1.22
1.22
1.22
1.22
1.22
1.22
HTS-D-2.4
HTS-D-3.2
HTS-D-4.8
HTS-D-6.4
HTS-D-7.9
HTS-D-9.5
HTS-D-12.7
HTS-D-15.0
HTS-D-19.1
HTS-D-25.4
HTS-D-30.0
HTS-D-39
HTS-D-50
HTS-D-64
HTS-D-75
HTS-D-90
HTS-D-100
HTS-D-125
0.9~2.2
1.0~3.1
1.8~4.6
2.4~6.4
2.9~7.7
3.4~9.4
4.4~12.5
5.4~14.8
6.5~18.8
8.8~25
10.5~30
14.0~9
17.5~49
22~62
26~72
32~88
36~90
44~125
Application
(
mm
)
Normal Packing 1
Normal Packing 2
Special Packing 1
Special Packing 2
